单项选择题
Design a logic circuit to produce a LOW output only if the input, represented by a 3-bit binary number (A is MSB and C is LSB), is between THREE and SIX (Including THREE and SIX). Use a 74LS138 (3-line-to-8-line decoder) and a few gates to implement the function(______).
请设计逻辑电路图满足要求:当输入的三位二进制数(A位权最高,C位权最低)在3和6之间(包含3和6)时输出为低电平。请用74LS138(3线-8线译码器)和少量必要的逻辑门实现这个逻辑功能(______)。

A.

B.


C.

D.
